Product Description
Specification
| Model Number | WD10EZEX |
| Performance | Formatted Capacity : 1TB Form factor : 3.5 inch Advanced Format (AF) : Yes RoHS Compliant : Yes Cache(MB) : 64 Performance Class : 7200 RPM Interface transfer rate Buffer to host : 6GB/s Host to/form drive (sustained) : 150MB/s Reliability/Data Integrity Load/unlooad cycles : 300,000 Non-recoverable read errors <1 in 10 |
| Power management | average power requirements (W) 12VDC +- 10% (A,Peak) : 2.5 Read/Write : 6.8 Idle : 6.1 Standby and Sleep : 1.2 |
| Enviromental Specifications | Temperature Operating 0 to 60 non-operating -40 to 70 Shock (Gs) Operating (2 ms , Read/write) : 30 Operating (2 ms , Read) : 65 Non-operating (2ms) : 350 Acoustics (dBA) Idle : 29 seek(average) : 30 |
| Physical Dimensions | Height (in/mm/max) : 1.028/26.1 Length (in/mm/max) : 5.787/147 Width (in/mm,+-.01in) : 4/101.6 weight (lb/kg,+-10%) : 0.99/0.45 |
| Warranty | 2 Years Western Digital Local Manufacturer Warranty |
What's in the box
Warranty
