Specifications
| POWER | ||
| AC adapter input | 100-240V ~ 50/60Hz 0.4A | |
| AC adapter output | 12V ⎓ 1.2A | |
| HARDWARE FEATURES | ||
| Processor | Qualcomm CPU | |
| Interface | 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit | |
| Button | 1 Reset button on the underside | |
| External Power Supply | 12 V/1.2 A | |
| Dimensions | Φ3.6 in. x 7.5 in. (Φ90.7 mm x 190 mm) | |
| Antenna Type | 2 internal dual-band antennas per Deco unit | |
| WIRELESS FEATURES | ||
| Wireless Standards | IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz | |
| Frequency | 2.4 GHz and 5 GHz | |
| Signal Rate | 300 Mbps on 2.4 GHz 867 Mbps on 5 GHz | |
| Transmit Power | FCC: <30 dBm CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) | |
| Wireless Security | WPA-PSK/WPA2-PSK | |
| Advanced Functions | ● Router/ Access Point Mode ● Optional Ethernet Backhaul ● Guest network ● TP-Link Mesh Technology: MU-MIMO Auto Path Selection Self-Healing AP Steering Band Steering Beamforming | |
| SOFTWARE FEATURES | ||
| Quality of Service | WMM | |
| IPv6 | Support | |
| WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP | |
| Management | Local Management, Remote Management | |
| DHCP | Server, Client | |
| Port Forwarding | Support | |
| Access Control | Blacklist | |
| Firewall Security | SPI Firewall | |
| Protocols | Supports IPv4 and IPv6 | |
| Advanced Features | Parental Controls Quality of Service | |
| Advanced Functions | Monthly Reports Auto FW Update Expand Wi-Fi by adding more Deco units | |
| Guest Network | 2.4 GHz guest network x 1 5 GHz guest network x 1 | |
| Beamforming | Support | |
| APP | Easy setup via Deco App | |
| OTHERS | ||
| Certification | FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS | |
| Package Contents | Deco M4 (2-pack): 2 Deco units 1 RJ45 Ethernet Cable 2 power adapters 1 quick installation guide | Deco M4 (3-pack): 3 Deco units 1 RJ45 Ethernet Cable 3 power adapters 1 quick installation guide |
| Smartphone/Tablet Requirements | iOS 9.0 or later, Android 4.4 or later | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing | |
