Product Description
At a Glance
Samsung’s SM863a SSDs feature our own V-NAND technology and are built from Samsung components. They are an ideal storage solution for write-intensive applications such as mail servers, data warehousing and high performance computing, providing high endurance for around the clock operations.
-Built for write-intensive enterprise applications with Samsung's proprietary 2-bit MLC V-NAND
-Built for sustained performance with strong IOPS consistency
-Tantalum capacitors for power loss protection
-Low latency and high quality of service (QoS)
Specification
Type
Product Type: SATA 6Gb/s
Series: SM863a
Application
Data Center: Yes
Storage
Capacity: 960GB
Key Features
Sequential Read Speed: 510MB/s
Sequential Write Speed: 485MB/s
Random Read Speed
Random Read IOPS (8KB): 55K
Random Read IPOS (4KB): 95K
Random Write Speed
Random Write IOPS (8KB): 9K
Random Write IPOS (4KB): 19K
CAS Latency: 50us
*Latency is measured using FIO with queue depth of 1 on 4KB random write
Controller: Mercury
NAND Flash: V-NAND
AES Encryption: AES 256-bit Encryption
General
Power Consumption (W): Read: 2.3W, Write:2.8W
Voltage: 5.0 V + 5%
Reliability (MTBF): 2.0 Million Hours Reliability (MTBF)
Environmental Specs
Operating Temperature: 0 °C to 70 °C
Non-operating Temperature: ~40 °C to 85 °C
Operating Humidity: 5% to 95%, non-condensing
Shock: 1500 G, duration 0.5 ms, Half Sine Wave
Form Factor
Product: 2.5" 7mm SATA
Dimensions (W x D x H)
Product: 10cm X 7cm X 0.69cm
Weight
Product: 59 grams
What's in the box
Warranty
