Product Description
Specification
| Form factor | M.2 2280 |
| Interface | PCIe Gen3x4 |
| Performance | 512GB - sequential read up to 3500MB/s, write up to 2400MB/s IOPS: up to 200/256K 1TB - sequential read up to 3500MB/s, write up to 3000MBs IOPS: up to 300/256K 2TB - sequential read up to 3500MB/s, write up to 3000MBs IOPS: up to 300/256K |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimension (L x W x H) | 80 mm x 22 mm x 2.25 mm / 3.15” x 0.87” x 0.09” |
| Weight | 9g |
| Warranty | 5 year limited warranty |
| Shock Resistant | 1500 G, duration 0.5ms, Half Sine Wave |
| Vibration Resistant | 10~2000Hz, 1.5mm, 20 G, 1 Oct/min, 30min/axis(X,Y,Z) |
| TBW | 2TB:1000, 1TB: 500TB, 512GB: 250TB, 256GB: 125TB |
| DWPD | 1TB: 0.44, 512GB: 0.44, 256GB: 0.44 |
| NAND flash | 3D TLC |
| MTBF | 1,500,000 Hours |
