| Model | CS-DB2 (2K) / CS-DB2-5MP (2K+) |
| Versions | A0-2C3WPB |
| Camera | |
| Image Sensor | 1/2.7" Progressive Scan CMOS (Supports low light sensitivity) |
| Lens | 2.0 mm F2.0, view angle : 176° (Diagonal) |
| Day & night | IR-Cut filter with auto-switching |
| DNR | 2D / 3D DNR |
| Video & Video Parameters | |
| Max. Resolution | 2000 × 1504 / 2544 × 1888 |
| Frame Rate | Max : 15fps. Self-Adaptive during Network Transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Full HD; HD; Standard. Adaptive Bit Rate. |
| Sensing Angle | 100º |
| Sensing Distance | Max. 5 m (16.4 ft) |
| Sensitivity | User adjustable (High, Medium and Low Sensitivity) |
| Function | |
| Intelligent Alarm | PIR + human shape smart motion detection |
| Tamper Alarm | Sound and light anti-dismantling alarm (supports sending alerts to the smartphone) |
| Video Intercom | Long-distance video two-way talk |
| Network | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Storage | |
| Local Storage | MicroSD card slot for local storage (Max. 256 GB) |
| General | |
| Operating Conditions | -20°C to 50°C (-4°F to 122°F), Humidity 95% or less (non-condensing) |
| Power Supply | DC5V±10% 2A |
| Power Consumption | Max. 2W |
| Battery Capacity | 5200mAh rechargeable lithium battery |
| Product Dimensions | 150 × 58 × 32 mm (5.91 × 2.28 × 1.24 inch) |
| Bare Weight | 0.24 kg (8.5 oz) |
| Package Contents | DB2 Video Doorbell / DB2 Pro Video Doorbell Chime Mounting Plates 2 x Inclined Mounting Plates 2 x Screwdriver and Screw Kits Foam Sticker Plate Foam Drill Template Pin 3 x U-shaped Wire and Wire Connectors Power Cable Regulatory Information Installation Guide Quick Start Guide |
| Certificates | UL / CE / FCC / REACH / WEEE / RoHS |
| Warranty | 2 Years Ezviz Local Manufacturer Warranty |
