Model | MPX-A503-AFAG-BUK / MPX-C503-AFAG-BUK |
PFC | Active PFC |
ATX Version | SFX 12V Ver. 3.42 |
Input Voltage | 100-240V |
Input Current | 13-7A / 15-7A |
Input Frequency | 47-63Hz |
Dimensions (L x W x H) | 160 x 150 x 86 mm |
Fan Size | 135 mm |
Efficiency | 90% @ Typical Load |
80 PLUS Rating | 80 PLUS Gold |
ErP 2014 Lot 3 | Yes |
Operating Temperature | 0-50°C |
Power Good Signal | 100 - 500 ms |
Hold Up Time | 16 ms |
MTBF | >100,000 Hours |
Protections | OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection |
Regulatory | cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.) |
ATX 24 Pin Connectors | 1 |
EPS 4+4 Pin Connectors | 1 |
EPS 8 Pin Connector | 1 |
SATA Connectors | 12 |
Peripheral 4 Pin Connectors | 4 |
PCI-e 6+2 Pin Connectors | 3 |
| 12VHPWR Connector | 1 |
Wattage | 1050W / 1250W |
80 Plus Efficiency | Gold |
Modular | Fully Modular |
Series | GX Series |
Warranty | 10 Years Local Manufacturer Warranty |
